Display type: 160 * 128 dots
LCD type: STN(Blue), transmissive/negative
Drive Method:1/128duty, 1/12bias, VOP 17.8V, VDD 5.0V
Backlight: White(side), VDD 5.0V, Idd 200mA
Drive IC: T6963(LQFP)
Viewing angle: 6 O’clock
Operating temperature: -20 to 70℃
Storage temperature: -30 to 80℃
Connection: ZEBRA
Outline dimension: 129.00mm(L)*102.00mm(W)*13.50mm(H)
Viewing area: 101.00mm(L)*82.00mm(W)
Active area: 92.76mm(L)*74.2mm(W)
Dots size: 0.54mm(L)*0.54mm(W)
Dots pitch: 0.58mm(L)*0.58mm(W)
